MORA tronic WMS, hospital mixer, battery operation

Find retailers
Description
Chrome, incl. s-connection (2x701001)
Article number
720305.DB
GTIN
7391887251337
Flow 3 bar
5.0 l/m

PROPERTIES

  • WMS-mixers with possibilities of wireless connection (subscription is required)
  • Adjustable hygiene flushing, intervals and rinsing time (to avoid stagnant water)
  • Logging of all flushings with point of time, water consumption and temperature for individual mixer or group of mixers (minimum, maximum and average values)
  • Battery monitoring
  • Built-in temperature measurements of mixed water temperature
  • Programmable temperature stop, the mixer will turn off directly at set maximum temperature
  • With thermostatic function
  • Temperature handle with safety stop at 38°C
  • Adjustable maximum temperature, pre-set to 42°C
  • Soft closing solenoid valve
  • Safe against vandalism, complete in metal
  • Eco (energy and water saving constant flow aerator, 5 l/min at 200–600 kPa)
  • With fixed spout
  • The mixer is activated by holding a hand in front of the sensor eye. Once started the mixer will run for at least 6 seconds and will continue to run as long as the hand is in front of the sensor.
  • Flush Timeout - safety shut-off to prevent flooding, maximum of 60 seconds
  • 60 sec. rinse time via sensor
  • Can be turned off by solenoid valve (eg for cleaning)
  • Low power consumption - Long life
  • Equipped with system for thermal disinfection against legionella
  • Battery operation, can be converted to mains operation
  • IP class sensor, IP67
  • Approved non-return valves, EN-Standard EN1717

    Installation:
  • Note! Gateway and a subscription is required for WMS
  • Automatic sensor calibration
  • Easy to change battery, without turning off the water supply
  • Mains operation requires installation of the AC adapter art.no. S600132 and power supply art.no. S600129, alternatively transformer art.no. S600128

    Settings:
  • Adjustable max temperature
  • With Gateway and WMS:
    - Hygiene flushing with adjustable time and intervals
    - Initiate hot water rinsing
    - Programming of rinsing times, temperature alarm och temperature stops
    - Alert signal if exceeding the time limit for stagnant water (the latest flushing)
K Tronic vägg 160cc och 150cc WMS.jpg
No. Art no. RSK Description
1 209611.AE On/off handle, complete (for basin mixer)
2 409373.AE End cover
3 209610.AE Stop ring (for basin mixer)
4 729555 Mixing valve (for basin mixer), Lead Free
4 16280100 Mixing valve (for basin mixer)
5 729455.AE 8553561 Solenoid valve
6 209608 Spout
7 131410.AE 8281509 Housing M22 int.
8 209607.AE Nipple
9 409365.AE 8187026 Nipple M18x1 - G1/2
10 729459.AE Cover plug for battery, black
11 459558 Spout
12 S600135 8483191 Battery
13 209605.AE Inlet connectors 150 c/c (left-handed thread)
14 209604.AE Filters, 2 pcs
15 209606.AE Inlet connectors 160 c/c
16 131356.AE 8281499 Aerator M24 ext.
17 729556 Termostatic unit (for shower- and hospital mixer)
18 209620.AE Stop ring (for shower- and hospital mixer)
19 209621.AE On/off handle, complete (for shower- and hospital mixer)
20 132205.AE 8281441 Aerator insert, 5 l/min at 200–600 kPa
21 729462.AE Electronic unit WMS (for shower mixer)
22 729463.AE Electronic unit WMS (for mixer with overhead spout)
23 729464.AE Electronic unit WMS (for mixer with underlaying spout)
24 729467.AE Limitation segment (for mixer with underlying spout)

Byggvarubedömningen

modal.bvb.desc;

Accepted installation instructions

Leadfree

Lead Free means that we have replaced the lead normally found in brass alloys. In this way, we get products with less environmental impact. Lead Free-labeled products contain less than 0.1% lead and are thus classified as lead-free.

Energyclass

The table below the product shows the energy class of the mixer. Certificates for energy labeling can be found under documents.
